SDG1050 Bench Waveform Generator

Description 50MHz Bench-top Arbitrary Waveform Generator (AWG) The SDG1050 arbitrary waveform generator from Siglent can generate waveforms of up to 50MHz and has 2 independent outputs.  It has an easy-to-use user interface, a 3.5″ screen and USB-Host, USB-Device and optional GPIB ports for remote control or uploading custom waveforms via flash disk or PC.  Furthermore, this waveform generator offers advanced functions like random noise, frequency sweeping (linear and logarithmic), modulation (AM, FM, PM, FSK, ASK, PWM) and burst mode.  The SDG-1050 also has a build-in 200MHz frequency counter. Specifications: Channels:  2 (independent operation) Frequency Range:  1uHz ~ 50MHz Frequency Accuracy:  100 ppm Sampling Frequency:  125 MS/s Output Voltage Range:  4mVpp ~ 20Vpp Resolution:  14 bit Advanced Features: Playback Modes:  Single-cycle, Repetitive, External-Triggered Wave Input Sources:  Predefined, GUI software Predefined Waves:  Sine, Square, Ramp, Pulse, Noise, Arbitrary, 48 predefined waveforms, defined via software Modulation Function:  AM, DSB-AM, FM, PM, FSK, ASK, PWM (Int or Ext carrier) Sweep Function:  yes Burst Function:  yes Simultaneous TTL Output:  yes Frequency Counter:  100MHz ~ 200MHz General: Power source:  100 ~ 240 VAC Computer Interface:  USB Host, USB Device, GPIB (optional) Display:  3.5″ colour TFT Dimensions (W×D×H):  229mm × 105mm × 281mm Weight:  2.6kg Package Includes The package includes the SDG1050 AWG, Quick start guide, Calibration certificate, Guarantee card, CD with software and manual, Power cord, USB cable. Please note: This AWG has been discontinued. Please have a look at its replacement models, the SDG1032X and SDG1062X.
