Description Top-End Multimeter with Power measurement & Analysis The Uni-T UT71E is a powerful top-end digital multimeter with features like power-measurement and -analysis. It can measure temperature, capacitance, frequency, and power together with all the other standard multimeter measurements. The UT71E has a built-in memory that can be used to store up to 100 measurements and a large display that includes a 5-digit display, two 4-digit displays, a bar graph, and numerous icons. Other functions included in this multimeter model are the backlight for use in the dark and a warning buzzer that alerts one when you plugged in the probes in the wrong input terminals. The UT71E has a built-in pass-fail/high-low alarm. Specifications: Basic Functions: DC Voltage: 0.01uV ~ 1000VDC VAC Voltage: 0.01uV ~ 750VAC Bandwidth: 100KHz AC Current: 001uA ~ 10A DC Current: 0.01uA ~ 10A Resistance: 0.01MΩ ~ 40MΩ Capacitance: 0.001nF ~ 40mF Temperature: -40°C ~ 1000°C Frequency: 0.001MHz ~ 400MHz Duty Cycle: 10% ~ 90% 4~20mA Current Loop : 0 ~ 100% Power Measurement: YES Voltage & Current : AC DC Measurement Diode: YES Continuity Buzzer: YES Special Functions: Auto Ranging Current Measurement Alarm Function Set Up True RMS Max/Min Mode Relative Mode Data Hold USB Double Display Backlight Data Logging 100 Data Recall Sleep Mode Low Battery Display Max. Display: 40000 Analogue Bar Graph Full Icon Display Peak Hold General: Power: 9V Battery LCD Size: 73 x 50m Product Colour: Red and Grey Product Net Weight: 384g Product Size: 200 x 93 x 40mm Multimeter Package Includes: UT71E Digital Multimeter, Test Lead, English Manual, Alligator Clip, USB Interface Cable, Software, Point Contact Temperature Probe, Travel Bag, Test Clip, Power Adaptor
